![Powermax Biomass Carbon Gasification Boiler System (Wood chips)-2](http://resourcewebsite.singoo.cc/image/65b31debde3ff.jpg)
Powermax Biomass Carbon Gasification Boiler System (Wood chips)-2
![](http://resourcewebsite.singoo.cc/attachment/6583ff019f2bb.jpg)
![](http://resourcewebsite.singoo.cc/attachment/6583ff0cf04d6.jpg)
![](http://resourcewebsite.singoo.cc/attachment/6582724922cf1.jpg)
![](http://resourcewebsite.singoo.cc/attachment/658272526ac9b.jpg)
![](http://resourcewebsite.singoo.cc/attachment/6582725edc3fb.jpg)
![](http://resourcewebsite.singoo.cc/attachment/65827269ad5ec.jpg)
Model of Gasification Boiler | UFBG-4TC | UFBG-6TC | UFBG-8TC | UFBG-10TC | UFBG-12TC | UFBG-15TC | UFBG-20TC |
Size of Boiler (steamed tons/hour) |
4 | 6 | 8 | 10 | 12 | 15 | 20 |
Size of Thermal Oil Boiler (kcal/h) |
2.4 million | 3.6 million | 4.8 million | 6 million | 7.2 million | 9 million | 12 million |
Biomass Consumption (kg/h) | APX. 1400-1600 | APX. 2000-240 | APX. 2700-3200 | APX. 3400-4000 | APX. 4000-4800 | APX. 5000-6000 | APX. 6700-8000 |
Gas Production (Nm3/h) | 2000-2200m3/h | 3000-3300m3/h | 4000-4400m3/h | 5000-5500m3/h | 6000-6600m3/h | 8000-8250m3/h | 9000-10000m3/h |
Gasifier Type | Updraft Fixed Bed Gasifier | ||||||
Gasification Agent | Air | ||||||
Size Requirement | 20-80mm | ||||||
Moisture Requirement (%) | 20-25% | ||||||
Adiabatic Flame Combustion temperature (℃) | 800-1200℃ | ||||||
Gas Outlet Temperature (℃) | ≤100℃ | ||||||
Gas Heat Value(Kcal/Nm3) | 1100-1500Kcal/Nm3 | ||||||
Charcoal Discharge Type | Rotating dry type | ||||||
Carbonization Yield % | About 10-15% |
![](http://resourcewebsite.singoo.cc/attachment/6582736e3b413.gif)
![](http://resourcewebsite.singoo.cc/attachment/6582727ace808.jpg)
![](http://resourcewebsite.singoo.cc/attachment/6583ff187a40a.jpg)
![](http://resourcewebsite.singoo.cc/attachment/658272b2ee568.jpg)
![](http://resourcewebsite.singoo.cc/attachment/658272c096458.jpg)
![](http://resourcewebsite.singoo.cc/attachment/658272cdd8270.jpg)
![](http://resourcewebsite.singoo.cc/attachment/658272e73187d.jpg)
![](http://resourcewebsite.singoo.cc/attachment/658273181f376.jpg)
![](http://resourcewebsite.singoo.cc/attachment/6582732ba941c.jpg)
![](http://resourcewebsite.singoo.cc/attachment/65827348459ae.jpg)
